제품 상세 정보:
결제 및 배송 조건:
|
| 장력 전단 강도: | 10Mpa의 위 | 인장 강도: | 55KN |
|---|---|---|---|
| T 껍질을 벗김 strengt: | 25mm 미만 | 신청: | Rebar 설치 |
| 수지 유형: | 변경된 순수한 에폭시 | 섞는 비율: | 3:1 |
| 능력: | 390ml | Rebar 크기: | Dia. 10-32 |
| 하이 라이트: | 360이지 밀리람베르트 순수 화학 앵커 접착제,두가지 실린더 케미칼 앵커 접착제,직접적 혼합 패키지 기초 앵커 접착제 |
||
Advantages/Benefits
▪ Excellent mortar bonding ensures highest loads in
concrete.
▪ Suitable for underwater installations.
▪ Suitable for diamond drilled holes.
▪ Expansion-free anchoring allows low axial spacings and
edge distances.
Our main product series
-- Concrete repair system
XQ-GF crack grouting adhesive
XQ-FF crack sealing adhesive
-- Steel bonding reinforcement system
XQ-JGN structural epoxy adhesive
XQ-GZ Grouting epoxy adhesive
XQ-FB edge sealing adhesive
-- Chemical Anchor series
Pure Epoxy Adhesive 360ml (5:1) 390ml(3:1) 585ml (3:1)
-- Carbon fiber reinforcement system,
XQ-XW carbon fiber epoxy adhesive
XQ-XB concrete surface leveling epoxy adhesive
XQ-CFC carbon fiber fabric 12K unidirectional 200gsm-600gsm
|
Testing project |
Condition |
Index |
||
|
Gel Performance (According to China National Standard GB50728-2011) |
||||
|
Splitting Tensile Strength (MPa) |
Under (23±2)℃,(50±5)%RH, tested by loading speed of 2mm/min |
≥8.5 |
||
|
Flexural Strength (MPa) |
≥50 (no fragment damage) |
|||
|
Compressive Strength (MPa) |
≥60 |
|||
|
Bonding Capacity (According to China National Standard GB50728-2011) |
||||
|
Steel-Steel Tensile Shear Strength (MPa) |
(23±2)℃,(50±5)%RH |
≥10 |
||
|
Bonding strength of Ribbed steel bar (or screw) with concrete under constrain drawing condition |
(23±2)℃ (50±5)%RH |
C30,Ф25,L=150mm |
≥11 |
|
|
C60,Ф25,L=150mm |
≥17 |
|||
|
Steel-Steel T-peeling strength (mm) |
(23±2)℃,(50±5)%RH |
≤25 |
||
|
Non-volatile content |
(105±2)℃,(180±5)min |
≥99% |
||
|
Ageing resistance to heat and humidity 90d |
||||
|
Reduction rate of tensile strength |
Under normal room temperature |
≤12% |
||
|
(According to China National Standard JGJ145-2013) |
||||
|
Tensile Strength (after high temperature welding) |
Dia12 Grade II steel, C30 concrete Hole dia.16mm, Depth: 150mm |
55.1N, 57.0N, 54.8N |
||
